Bailey Bridge Frame

Function: Used for various steel bridges and Bailey frames.

WhatsApp:

Share to

  • 产品描述
  • Bailey Bridge Frame

    Material: Q235
    Brand: Xingming
    Type: Heavy
    Quality control: 100% quality inspected
    Processing Service: Welding
    Size: 45/60/90/120/135 series Bailey bridge frame
    Place of Origin: Hebei, China
    Tolerance: ±3%
    Surface treatment: Custom colors
    Application: Steel Structure Bridge

    Product Name
    Bailey bridge support frame
    Size
    45/60/90/120/135 series Bailey bridge support frame
    Main Components

    1. Pin & Cotter Pin: Made of high-strength alloy steel for connecting panels

    2. 321 Type Panel: Standard size: 3m×1.5m, universal core component

    3. 200 Type Panel: Standard size: 2m×1.5m, suitable for flexible layouts.
    4. Reinforced Panel: Same size as 321 type with enhanced load capacity
    Connection System
    1. Transom Beam: I-beam, installed at the bottom nodes to support the deck.
    2. Transom Clamp: Used to secure the transom beam to the lower chord.
    3. Bracing & Sway Frame: Includes horizontal and vertical bracing for stability.
    Deck System
    Stringer: Mounted on transoms to support decking panels.
    Supports
    1. Bearing & Launching Nose: Includes rocker, base plate, etc., for end support.
    2. Sway Bracing: Reinforces the lateral stability of the bridge.
    3. High-Strength Bolt: For connecting various support components.

    Specifications
    1. Bailey bridge 45/60/90/120/135 frame

    2. Parts of the Bailey bridge

    3. High quality and low price

    4. Factory exports directly



    Features:

    1. Attractive design: the whole looks beautiful and elegant.

    2. Lightweight and convenient for shipping

    3. Easy to assemble and dismantle: the warehouse can be rebuilt dozens of times. The assembly only requires simple tools.

    4. Firm structure: the warehouse adopts a steel frame structure and sandwich panels.

    5. Durable: the steel frame parts are all processed with anti-corrosion coating.
